Geometry
Geometry

-
A - Handlebar Length
28.7"/73cm
-
B - Total Length
70.1"/ 178cm
-
C - Total Height
40.9"/ 104cm
-
D - Seat Length
17.5"/ 44.5cm
-
E - Top Tube Length
31.1"/79cm
-
F - Tire Width
2.6"/ 6.5cm
-
G - Wheel Diameter
23.2"/ 59cm
-
H - Seat Height
31.7"/ 80.5cm
-
I - Wheelbase
46.5"/ 118cm
-
J - Suspension Length
31.5"/ 80cm
-
K - Seat Height from Tire
9.8"/ 25cm
-
L - Battery Length
15.4"/ 39cm
Specification
Specification
-
Motor Power (Peak)
3000W Mid drive Brushless Motor
-
Battery
60V, 25Ah(1500Wh)
-
Riding Range
32-80KM (20mi -50mi)
-
Frame
High-strength Steel Pipe
-
Display
LCD Display
-
Max Loading
264 lbs (120kg)
-
Net Weight
53 KG
-
Charging Time
5-8H
-
Transmission Gears
This transmission system achieves a 1:9.6 reduction ratio via two - stage speed reduction. The first stage uses a pulley (23:51 ratio), and the second uses a chain sprocket (13:56 ratio)
-
Brake System
Hydraulic Brake
-
Wheel Size & Tires
3.15×17 Inches Tires
-
Suspension
High - Performance Hydraulic Front & Rear Shock Absorbers
-
Rear Brake Light
Yes
-
Package Size
59*11.8*32inch (150*30*83cm)
-
Suggested Rider Height
4'8"-6'1" (144-186cm)
what's in the box
what's in the box
-
80/100-17(3.15×17") Tire*2
-
60V, 25AH
-
Charger*1
-
Pedals*2
-
Front and rear light
-
Owner's manual
-
Bicycle Seat
-
Bicycle frame
